Convention Center, Hotel 2D DWG Plan for AutoCAD
Plan, section and elevation view of convention center. The floor plan has following areas – entrance, hotel, convention center, recreational area, patio, terrace of special event, master conference room, elevator, laundry, staircase, bar, car parking lot, combustible room, loading and discharge area, night club disco, pools, tennis court, area of alternative activities, dining room, reception, living room. Plan and section view shows the electrical installations and construction details of convention center. The entire area is covered by gardening and landscaping. Total foot print area of the plan is approximately 66,300 sq meters.
Language | Spanish |
Drawing Type | Plan |
Category | Hotel, Restaurants & Recreation |
Additional Screenshots |
![]() ![]() |
File Type | dwg |
Materials | Aluminum, Concrete, Glass, Masonry, Moulding, Plastic, Steel, Wood |
Measurement Units | Metric |
Footprint Area | Over 5000 m² (53819.5 ft²) |
Building Features | A/C, Pool, Fireplace, Garage, Deck / Patio, Elevator, Escalator, Car Parking Lot, Garden / Park |
Tags | appartment, autocad, block, center, convention, CONVENTION CENTER, DWG, Hotel, Restaurant |
