Dams 3D DWG Model for AutoCAD

Dams 3D DWG Model for AutoCAD

Dams views in 3D with topographic plant

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Approximate capacity lock, Considering approximate area around the contour:, Maximum quota bar, Context sentences

Raw text data extracted from CAD file:

E 990 E 1015 E 1040 N 989 N 1014 N 1039 N 1064 N 1089 1:250 100 99 98 98 98 98 98 98 97 97 97 97 97 97 96 96 96 96 96 96 95 95 95 95 94 94 94 94 93 93 93 93 92 92 92 92 91 91 91 91 90 90 90 CAPACIDAD APROXIMADA TRANQUE : 11.500 M 3 AREA APROXIMADA TRANQUE CONSIDERANDO 3mts POR TODO EL CONTORNO: 4.800 M 2 COTA MAXIMA TRANQUE 95.5 COTA FONDO TRANQUE 90.0

Language	Spanish
Drawing Type	Model
Category	Water Sewage & Electricity Infrastructure
