Data DWG Full Project for AutoCAD

This is intented to show the basic UTP wiring and terminations for basic horizontal cabling for voice and data. Various organizations use CAT 5E or CAT 5 for Data. This riser diagram specifies CAT 6. There is a short specification included. This detail is perfect for small projects requiring additional voice and/or data outlets.

Drawing labels, details, and other text information extracted from the CAD file:

by contractor, nomenclature for quantity of data and voice ports:, data, ex data switch, single gang outlet, ex phone switch, voice, verizon, existing, punchdown, main

Raw text data extracted from CAD file:

RISER DIAGRAM: VOICE & DATA *SEE VICINITY MAP FOR LOCATION BY CONTRACTOR TERMINATIONS/CONNECTIONS CONNECT AND EXTEND 1-4PAIR CAT6 TO EACH VOICE AND/OR DATA JACK AND EXTEND TO INDICATED WIRING CLOSET. NEW COMBINATION (WHERE APPLICABLE) VOICE/DATA OUTLET. NUMBER OF DATA AND/OR VOICE JACKS AS INDICATED. TERMINATE AND CONNECT AT RESPECTIVE STATIONS, 110 BLOCKS AND CAT 5 PANEL. TEST AND CERTIFY ALL NEW LINES. NOMENCLATURE FOR QUANTITY OF DATA AND VOICE PORTS: CONTRACTOR WILL PROVIDE ALL WIRE MANAGEMENT RINGS, LADDER RACK, BRACKETS, WIRE MANAGEMENT PANELS WHICH, IN THE SOLE JUDGMENT OF THE UNIVERSITY SHALL BE REQUIRED FOR A NEAT AND WORKMANLIKE INSTALLATION. CONTRACTOR TO SUPPLY/INSTALL THE NECESSARY AMOUNT OF VOICE AND DATA PUNCHDOWN HARDWARE IN THE PRESENT WIRING CLOSET TO ACCOMODATE CONNECTIONS OF ALL NEW VOICE AND DATA LINES.WHERE APPLICABLE, PROVIDE/INSTALL ADDITIONAL CAT6 48-PORT UTP PANEL(S) AND TELEPHONE 110 BLOCK(S). ALL CABLE, WORKSTATION OUTLET, AND WIRE ROOM EQUIPMENT INSTALLATION SHALL BE IN STRICT ACCORDANCE WITH THE METHODOLOGIES CONTAINED IN THE LATEST BICSI TELECOMMUNITCATIONS DISTRIBUTION METHODS MANUAL. THIS INCLUDES, BUT IS NOT LIMITED TO, CABLE ATTACHMENTS, FIRESTOPPING, CABLE ROUTING, EQUPMENT RACK GROUNDING & BONDING, PULLING TENSIONS AND EMF PROTECTION METHODS. CABLES SHALL BE NEATLY ROUTED AND BUNDLED ABOVE THE DROP CEILINGS IN BUNDLES CONTAINING FIFTY (50) CALBES OR LESS, AND BE PROPERLY SUPPORTED TO MINIMIZE PAIR DISTORTION. THE USE OF CABLE TRAY IS MOST APPROPRIATE. CATEGORY 6 J-TYPE HOOKS OR BRIDLE RINGS MAY BE USED FOR ADDS/MOVES/CHANGES. HORIZONTAL CABLE ALL CABLES WILL BE INSTALLED, TESTED, LABELED AND DOCUMENTED AS SPECIFIED HEREIN. TELECOMMUNICATIONS OUTLETS SHALL BE INSTALLED WITH A MINIMUM OF 2 DATA CABLES AND ONE VOICE CABLE PER OUTLET. SOME AREAS MAY REQUIRE DATA ONLY TO MAXIMIZE PORT DENSITY. THE HORIZONTAL CABLES SUPPORTING VOICE AND DATA COMMUNICATIONS SHALL BE 4-PAIR, UNSHIELDED TWISTED PAIR (UTP) ENHANCED CATEGORY 6 (1000 MHZ) COPPER CABLE WITH ALL PAIRS INSULATED WITH 100% FEP. CABLES SHALL BE OF A QUALITY AND TYPE, SUCH AS BERK-TEK LANMARK 1000 SERIES (CATEGORY 6),BERK-TEK LANMARK 2000 SERIES (ENHANCED CATEGORY 6),BELDEN/CDT 2400 SERIES (CATEGORY 6),BELDEN/CDT 4800LX SERIES (ENHANCED CATEGORY 6), OR AN NTS APPROVED EQUAL. VOICE / DATA JACKS VOICE/DATA JACKS SHALL BE 8-POSITION MODULAR JACKS AND SHALL BE CATEGORY 6 PERFORMANCE AS DEFINED BY THE REFERENCES IN THIS DOCUMENT INCLUDING ANSI/TIA/EIA-568-B.2-1. ALL PAIR COMBINATIONS MUST BE CONSIDERED, WITH THE WORST-CASE MEASUREMENT BEING THE BASIS FOR COMPLIANCE. MODULAR JACK PERFORMANCE SHALL BE THIRD-PARTY VERIFIED BY A NATIONALLY RECOGNIZED INDEPENDENT TESTING LABORATORY. THE MODULAR JACK SHALL USE DUAL REACTANCE MODULAR CONTACT ARRAY. THE MODULAR JACK SHALL HAVE LOW EMISSION IDC CONTACTS. THE MODULAR JACK SHALL USE STANDARD TERMINATION PRACTICE USING 110 IMPACT TOOL THE MODULAR JACK SHALL BE BACKWARDS COMPATIBLE TO CATEGORY 3, 5, AND 5E. THE MODULAR JACK SHALL BE CENTER TUNED TO CATEGORY 6 TEST SPECIFICATIONS. JACKS TO BE ORTRONICS CATEGORY 6 T568A/B TRACJACK, 180° EXIT, MODEL OR-TJ600-XX PATCH PANELS MODULES USED ON THE UTP PATCH PANEL WILL BE EIA CATEGORY/LEVEL 6 RATED AND WILL BE WIRED IN ACCORDANCE WITH EIA STANDARD 568B, THE SAME AS THE DATA OUTLET JACKS. EACH PANEL SHALL BE LAID OUT IN A STATION/ROOM NUMBER SEQUENCE. THE CONTRACTOR MUST PROVIDE A SUFFICIENT QUANTITY OF REQUIRED PATCH PANELS TO TERMINATE ALL DATA CABLES BEING SERVED BY THE RACK. UNLESS OTHERWISE PRE-APPROVED, THE ONLY PATCH PANEL SIZE(S) TO BE USED FOR UTP IS ONE CONSISTING OF 48 PORTS, AN APPROVED UTP PATCH PANEL IS 48 PORT BELDEN/CDT GIGAFLEX PS6+ PATCH PANEL, 48 PORT (AX101613) OR ORTRONICS CLARITY6 CATEGORY 6 PATCH PANELS, 48 PORT, 8 PORT MODULES (OR-PHD68U48).WIRE MANAGEMENT PANELS MUST BE INSTALLED BETWEEN EACH 48 PORT PATCH PANEL TYPE. OUTLETS THE CONTRACTOR MUST USE A MODULAR JACK, GANG BOX, AND FACEPLATE ASSEMBLY – ORTRONICS NETCLEAR SERIES. THE CONTRACTOR SHALL TERMINATE ALL 8P8C OUTLETS IN THE T568B PIN/PAIR CONFIGURATION. ALL FOUR PAIRS SHALL BE TERMINATED. THE CONTRACTOR SHALL INSTALL COLOR-CODED (SHALL MATCH OUTLET COLOR) DESIGNATION SHUTTERS/DOORS ON ALL DATA/VOICE WORK AREA OUTLETS. THE CONTRACTOR SHALL INSTALL COLOR-CODED ICON TABS (SHALL MATCH OUTLET COLOR) ON ALL WORK AREA OUTLETS. THE CONTRACTOR SHALL INSTALL ALL OUTLETS IN A NEAT AND PROFESSIONAL MANNER TO THE SATISFACTION OF JH. THE CONTRACTOR SHALL INSTALL OUTLETS IN LAYOUTS SHOWN IN THE ATTACHED DRAWINGS. FACEPLATE: DATA OUTLETS, SHALL CONSIST OF A MODULAR WALL PLATE WITH SIX 8-POSITION RJ-45 DATA JACK. DATA JACKS WILL BE RATED FOR EIA ENHANCED CATEGORY 6 PERFORMANCE. ALL 4 PAIRS OF EACH DATA JACK SHALL BE WIRED IN ACCORDANCE WITH EIA STANDARD 568-B.ORTRONICS SINGLE GANG, FOG WHITE, 6-PORT, TRACJACK FACEPLATES (OR-40300545). MODULES: ORTRONICS CLARITY6 CATEGORY 6 TRACJACK MODULES, BLUE, 8P8C, 180° EXIT (OR-TJ600) FOR DATA; ORTRONICS CLARITY5E CATEGORY 5E TRACJACK MODULES, FOG WHITE, 8P8C, 180° EXIT (OR-TJ500) FOR VOICE SHUTTERS:ORTRONICS COLOR CODED DESIGNATION SHUTTERS ON ALL MODULES (BLUE- OR-20326155 FOR DATA; FOG WHITE -OR-20309154 FOR VOICE) BLANKS: ORTRONICS TRACJACK BLANK MODULES, AS NEEDED LABELING ALL PROJECTS WILL REQUIRE THAT ALL CABLES AND ASSOCIATED HARDWARE BE APPROPRIATELY LABELED IN ACCORDANCE WITH TIA\\EIA-606 STANDARDS IN CONJUNCTION WITH JHMI LABELING PRACTICES. THE PURPOSE OF USING A LABELING STANDARD IS TO PROVIDE A UNIFORM ADMINISTRATION SCHEME THAT IS INDEPENDENT OF APPLICATIONS, BECAUSE APPLICATIONS MAY CHANGE SEVERAL TIMES THROUGHOUT THE LIFE OF THE BUILDING. TESTING ALL HORIZONTAL UTP COPPER CABLING SUPPORTING VOICE AND DATA COMMUNICATIONS REQUIREMENTS SHALL BE TESTED FOR PERFORMANCE AT 1000 MHZ. THE CONTRACTOR SHALL PROVIDE THE CATEGORY 6, 1000 MHZ TEST RESULTS ON ALL PAIRS OF CABLE. ** FOR NEW TELEPHONE EXTENSIONS, WHERE APPLICABLE QUANTITY OF CABLES/ CONNECTIONS PER PLANS QUANTITY OF DATA/ VOICE PORTS AND ASSOCIATED TYPICAL 6-PORT TELEPHONE/DATA IN TELCOM CLOSET* DATA TERMINATIONS/CONNECTIONS CAT 6 CROSS-CONNECT (TYP) EXISTING (OR NEW) UTP PANEL* CAT 6 48 PORT @ BOTH ENDS EX DATA SWITCH (JHMI) (JHMI) (CONTRACTOR) 4- PAIR UTP CAT6 CABLE SINGLE GANG OUTLET (CONTRACTOR) 4- PAIR UTP CAT 6 CABLE CAT6 CROSS-CONNECT (TYP) EXISTING (OR NEW) 110 BLOCK* TERMINATIONS/CONNECTIONS @ BOTH ENDS @ BOTH ENDS D D EX PHONE SWITCH 110 BLOCK BY VERIZON** @ BOTH ENDS TERMINATIONS/CONNECTIONS VOICE IN TELCOM CLOSET* VERIZON EXISTING PUNCHDOWN EXISTING VERIZON MAIN (JHMI) (JHMI) 2D = (2) DATA, 6D = (6) DATA, ETC. NO DESIGNATION or 2D/1V = (2) DATA/ (1) VOICE D D V V
