EXAGONAL POST DETAIL;FOR EXTERIOR LIGHTING

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Hexagonal lamp post with double whip type arm, Hexagonal post, Metal halide luminaire v., Double whip type arm, Prepared by: ing. Eduardo diaz c.i.v. C.i.

Raw text data extracted from CAD file:

\A1;0.80 \A1;0.40 \W6.73049; POSTE HEXAGONAL PARA \W9.37979; ALUMBRADO \W0.96351; CON BRAZO DOBLE TIPO LÁTIGO Poste Hexagonal \W0.50945; Luminaria Metal Halide \W7.52105; 150 W, 240 V. Brazo tipo Látigo doble 6.00 m 8.00 m 1.83 m 1.83 m 0.45 m \A1;0.40 0.80 0.40 \W1.44427; ELABORADO POR: ING. EDUARDO DÍAZ \W8.22723; C.I.V. 207.351 \W8.21198; C.I. 17646100
