Drawing board for architecture students has easily adapted and anthropometric studies ergonometric addition to its detailed construction

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

drawing board sheet base study module, plant, front, back, side cut, front cut, drawing board, mobile union, metal base, rail, drawing board, rail, slider shaft, regulation handle, mobile union, base, metal handle, type of joint and screwed board, type of joint weld, type of joint mobile hinge, needs:, activities:, materials:, objectives:, reduce the minimum space in certain opportunities, the main objective of this project is that this module fits anthropo metrically and activities that take place within an architectural classroom, the module is adaptable to the function or activity that can be performed in the environment, material, und., regulation handle, und., total cost of materials, equipment and machine wear, labor, total price x module

Raw text data extracted from CAD file:

0.70 0.18 0.04 0.92 1.30 0.58 0.55 0.50 0.50 0.49 0.62 0.50 1.30 0.69 0.93 1.30 0.02 0.02 0.49 0.62 0.02 tablero de dibujo base de laminas modulo de estudio 0.87 0.58 0.98 1.61 0.94 0.58 1.90 1.71 5 5 5 5 <> \C250;PLANOS : PLANTA 5 5 5 FRONTAL POSTERIOR <> 5 5 5 \C250;CORTES : \C250;PERSPECTIVAS : \C250;ANTROPOMETRIA : \C250;MATERIALES : CORTE LATERAL CORTE FFRONTAL 5 5 5 5 5 5 5 5 tablero de dibujo union movil base metalica union movil carril TABLERO DE DIBUJO CARRIL EJE DESLISANTE MANIJA DE REGULACION UNION MOVIL BASE MELAMINE 1" LISTON DE MADERA RECTANGULAR 2"x11/4" 5 TUBO REC. O 2"x11/4" TUBO REC. O 2"x11/4" TUBO REC. O 2 1/4"x1" TUBO RED. O 1"x 1.2mm. LISTON DE MADERA RECTANGULAR 2"x11/4" TALLADA MANIJA METALICA TUBO RED. O 1"x 1.2mm. TUBO RED. O 1"x 1.2mm. tipo de junta contraplacado y atornillado tipo de junta soldadura tipo de junta soldadura tipo de junta bisagra movil tipo de junta contraplacado y atornillado \C250;precios : \C250;ERGONOMETRIA : NECESIDADES : ACTIVIDADES : MATERIALES : OBJETIVOS : reducir el minimo de espacio en ciertas oportunidades tablero de dibujo base de laminas modulo de estudio MELAMINE 1" LISTON DE MADERA RECTANGULAR 2"x11/4" TUBO REC. O 2"x11/4" TUBO REC. O 2 1/4"x1" TUBO RED. O 1"x 1.2mm. TORNILLOS 11/2" el objetivo principal de este proyecto es que este modulo se adapte antropo metricamente y a las actividades que se desarrollan dentro de un aula de arquitectura el modulo es adaptable a la funcion o actividad que se puedan realizar en el ambiente empiesa a un angulo base de 90 el cual es comodo para actividades de escritura (fig.1) y es adaptable para actividades de dibujo ; adaptandose a caulquier altura deseada por el usuario (fig2) \C250;1 \C250;2 \C250;3 tambien es de necesidad bases para las laminas en caso de presentaciones dando a si el ahorro de espacio y mejorando la calidad de presentacion (fig.3) MELAMINE 1" LISTON DE MADERA RECTANGULAR 2"x11/4" TUBO REC. O 2"x11/4" TUBO REC. O 21/4"x1" TUBO RED. O 1"x 1.2mm. TORNILLOS 11/2" MATERIAL UND. PRECIO s/. 1.83x2.50 500 unds. 7 metros 7 metros 7 metros 7mc/u MANIJA DE REGULACION MANIJA DE REGULACION 182.00 18.00 und. 15.00 18.00 35.00 25.00 32.00 5 5 5 5 5 5 5 5 MELAMINE 1" LISTON DE MADERA RECTANGULAR 2"x11/4" TUBO REC. O 2"x11/4" TUBO REC. O 21/4"x1" TUBO RED. O 1"x 1.2mm. TORNILLOS 11/2" 1.30x0.70 100 unds. 3.95 m. 0.55 m. 6.70 m. MANIJA DE REGULACION 60.66 4.00 2 unds 30.00 10.66 2.75 25.00 19.20 4.20 m. \C250;requerimientos : costo total materiales 157.27 desgastamiento de equipos y maquinas mano de obra 25% 5% 39.31 7.60 gastos extra (pegamento,soldadura.etc) 35% 53.00 precio total X modulo 257.18
