Electric Simbologia DWG Block for AutoCAD

Electric Simbologia DWG Block for AutoCAD

form cad

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Icft, Electrical installation specifications, symbol, Type load center with thermomagnetic switches, Center outlet with block socket, For fluororescent focus of volts, With urea block block, For fluororescent focus of volts, With urea block block, Simple eraser, Staircase eraser, Ring button, With ground pole, Polarized duplex contact, Polarized single contact, With ground pole, Buzzer watts, Pipe inst. Telephony by floor poliducto, Pipe inst. Antenna by slab poliducto, Pipe inst. Electric per floor, Tube inst. Electric by slab wall, With ground pole, Duplex contact polarized in floor, With ground pole, Duplex contact polarized weather, With icft ma, Polarized duplex contact, With icft ma, Polarized duplex contact, With ground pole, Polarized duplex contact, With ground pole, Polarized duplex contact, Pipe rises, Low pipe, With icft ma, Polarized duplex contact

Raw text data extracted from CAD file:

T T T T ICFT ICFT ICFT ICFT T ESPECIFICACIONES INSTALACION ELECTRICA D E S C R I P C I O N A L T U R A S SIMBOLO CENTRO DE CARGA TIPO QO-12 CON INTERRUPTORES TERMOMAGNETICOS SALIDA DE CENTRO CON BLOCK SOQUET PARA FOCO FLUORECENTE DE 23W A 120 VOLTS PARA FOCO FLUORECENTE DE 23W A 120 VOLTS SALIDA ARBOTANTE CON BLOCK SOQUET ó de UREA DE 19mm PARA FOCO FLUORECENTE DE 23W A 120 VOLTS (INTEMPERIE) SALIDA ARBOTANTE CON BLOCK SOQUET ó de UREA DE 19mm APAGADOR SENCILLO 10 a/120 v APAGADOR ESCALERA 10 a/127 v BOTON DE TIMBRE Con polo a TIERRA CONTACTO DUPLEX POLARIZADO 15 a/120v CONTACTO SENCILLO POLARIZADO 15 a/120v Con polo a TIERRA ZUMBADOR 40 watts - 120 V TUBERIA INST. TELEFONIA POR PISO T-3/4 POLIDUCTO TUBERIA INST. ANTENA POR LOSA T-3/4 POLIDUCTO TUBERIA INST. ELECTRICA POR PISO TUBO INST. ELECTRICA POR MURO ó LOSA Con polo a TIERRA CONTACTO DUPLEX POLARIZADO EN PISO 15 a/120v Con polo a TIERRA CONTACTO DUPLEX POLARIZADO INTEMPERIE 15 a/120v, Con ICFT 6 ma CONTACTO DUPLEX POLARIZADO 15 a/120v Con ICFT 6 ma CONTACTO DUPLEX POLARIZADO 15 a/120v Con polo a TIERRA CONTACTO DUPLEX POLARIZADO 15 a/120v Con polo a TIERRA CONTACTO DUPLEX POLARIZADO 15 a/120v, 1000 w Tuberia Sube Tuberia Baja Con ICFT 6 ma CONTACTO DUPLEX POLARIZADO 15 a/120v,1500 w

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features	Car Parking Lot
Tags	autocad, block, cad, DWG, einrichtungen, electric, facilities, form, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, simbologia, wasser bestimmung, water
