This detail is section and plan of an emergency electronic door with 2sides.

Drawing labels, details, and other text information extracted from the CAD file:

unit width, maximum slide, floor plan, n.t.s., elevation, finished floor, unit height, exterior side, safety beam, full scale, horizontal section, rough opening, door shown in open position, vertical section, emergency breakout

Raw text data extracted from CAD file:

UNIT WIDTH 2 MAXIMUM SLIDE FLOOR PLAN N.T.S. N.T.S. ELEVATION 120 VAC 1/4" (6mm) 1 2 1 FINISHED FLOOR UNIT HEIGHT EXTERIOR SIDE SAFETY BEAM UNIT WIDTH FULL SCALE HORIZONTAL SECTION EXTERIOR SIDE ROUGH OPENING FULL SCALE DOOR SHOWN IN OPEN POSITION VERTICAL SECTION 1/4" (6mm) ROUGH OPENING UNIT HEIGHT EMERGENCY BREAKOUT
