Detailed technical drawing of a Faymonville Mega-Z 2L V-ATX low-bed trailer with lateral and plan views. The semi-trailer features a hydraulic gooseneck front section with reinforced loading surface and dual-axle rear bogie configuration. Key measurements include an approximate overall length of 15,886mm and width of 2,800mm. The trailer is designed with a maximum technical, essentially, axle load capacity of 12,000kg per axle on the rear bogie and 23,000kg on the gooseneck. The drawing shows both loaded and unloaded states (*cargado/**vacio) with R17.5° tire profile and 245/70 tire size specification. Notable structural elements include adjustable loading height, hydraulic suspension, and stabilizing outriggers. The trailer’s design accommodates oversized heavy equipment transport with compliance to European dimensional regulations.
Faymonville Mega-Z 2L V-ATX Low-Bed Trailer Technical Drawing
