Footbridge DWG Full Project for AutoCAD

Project located in Puerto Cabello, Carabobo State. AREA 2 AREA IDENTIFIED IN AREAS SURROUNDING AIRPORT LOUNGE BARTOLOME. THE PROJECT IS TO DESIGN A NEW PROFILE ROAD and street furniture. Among which are: METRO STOPS, WALKWAYS, LIGHTING, BANKS, Telephone Booth, PAPER; Activity Modules; security checkpoints.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

facade, roof plant, cut-to-a ‘, plant

Raw text data extracted from CAD file:

A’ A A’ FACHADA PLANTA TECHO CORTE A-A’ FACHADA PLANTA +6.20 ±0.00 +5.00 +9.00 +6.20 ±0.00 +6.20 +6.20 FACHADA +6.20 ±0.00
