Detailed mesh guard for industrial vehicle cabs or heavy equipment. Specifically shows the ROPS / FOPS protective structure used for safety. Includes main frame rails, support posts, and the top safety mesh. Imperial units used, overall drawing footprint is about 23″ x 22″. Comes with organized layers for different parts like AFUCH-3-BKMS for the back mesh & AFUCH-3-STPL for steel plates.The blue mesh is pretty dense for overhead protection from falling objects etc
Heavy Equipment Cab Safety Mesh and FOPS Guard Detail
