office floor layout showing core with 8 cabs, toilest, and egress stairs. includes annotations for smoke zones, fire protection (SP-HQ17-01), and HVAC. workstation blocks shown with 30×72 surfaces and typ. 42″ high partitions. we’ve got telecom hubs and conference areas laid out too.
HQ-17 Office Floor Layout
