Hydraulic feeding air to washing machines; with valve control field

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

male connector, Removable ball valve, Tee, Elbow, Union nut, Mod air washer unit, Mca. Master cool, Furniture relationship, Ball valve, Nut union pipe tube diameter mm., Hermetic seal type master flash epdm, Materials relationship, Male connector of tuboplus brand of diameter., Elbow mm brand tuboplus., Tubular tube of diameter mm., Tee of mm brand tuboplus., Check height at work, Check height at work, N.p.t., Front elevation, Isometric

Raw text data extracted from CAD file:

200051 Conector Macho 20mm x 1/2" 1/2" x 1/2" 20 1/2 27 38 16 53 12 200252 Válvula de Esfera Desmontable de 20mm x 20mm 1/2" x 1/2" 26 20 42 12 82 27 54 16 1/2 Tee de 20mm 200178 4.5 29 20 200014 Codo de 90° de 20mm 1/2" 27 29 15 20 46 46 42 20 29 1/2" x 1/2" Tuerca unión de 20mm x 20mm 200232 4.5 1 0.40 m 0.19 1.31 m 2.18 0.40 UNIDAD LAVADORA DE AIRE MOD MD32012E MCA. MASTER COOL A A RELACIÓN MOBILIARIO Valvula esfera desmontable, marca Tuboplus de 20 mm de diámetro Tuerca unión PP-R, marca Tuboplus de 20 mm de diámetro. 1 2 3 4 5 6 Sello hermetico tipo Master Flash EPDM de 1/4" a 2" 7 RELACIÓN MATERIALES 1 2 3 4 5 6 4 5 1 2 3 7 Conector Macho de PP-R, marca Tuboplus de 20 x 1/2" de diámetro. Codo 90 x 20 mm PP-R, marca Tuboplus. Tubo de PP-R, marca Tuboplus de 20 mm de diámetro. Tee de 20 mm PP-R, marca Tuboplus. 0.40 m Verificar altura en obra 0.19 1.31 m 2.18 0.40 1.87 m 2.17 m 1.31 m 0.40 m Verificar altura en obra 3 4 5 6 3 4 5 7 N.P.T. ALZADO FRONTAL ISOMETRICO

Language	Spanish
Drawing Type	Block
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features	Car Parking Lot
