This detailed drawing depicts the main entrance door assembly for an end villa unit within a 4PLEX townhouse development. The door features a solid wood construction with decorative horizontal panels and integrated ironmongery. The assembly includes a complete frame system with architraves, packers, and seals. The door measures approximately 1200mm wide by 2300mm high, with a sophisticated frame detail that incorporates stone thresholds at the base. The drawing provides multiple views including front elevation, side section, and plan detail showing hinge placement and latch mechanisms. Notable design considerations include weatherproofing details where the frame meets the stone threshold and specialized seals around the perimeter. The construction incorporates a combination of wood veneer finishes with ironmongery hardware that complies with standard residential specifications. The drawing provides dimensional references for installation heights including floor levels at +0.00, with relationship to story heights at +4.50, +7.50, and +10.50 meters.
Main Entrance Door Detail for 4PLEX End Villa with Frame Assembly
