Master Suite DWG Plan for AutoCAD

Master Suite DWG Plan for AutoCAD

floor plan of a room in a hotel in gt

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

iglu, terrace, bar, bedroom, jacuzzi, bathroom, kitchen, bedroom, cut a – a ‘, cut b – b’, master suite of one room, duct

Raw text data extracted from CAD file:

IGLU 3,2 3,5 3,2 3,5 2,11 1,72 3,1 5,89 3,12 11,02 Terraza Bar Recmara Jacuzzi Baño Cocina A A' Recamara Jacuzzi B' B Cocina Recmara Terraza Corte A - A' Corte B - B' Master Suite de una Habitación Ducto 5 0,3 0,5 5 5 0,3 0,5 5 A E B C D 5 5 5 5 5 A B C E 5

Language	Spanish
Drawing Type	Plan
Category	Hotel, Restaurants & Recreation
