Metallic Doble Gate DWG Detail for AutoCAD

Detail double metallic gate

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

structural concrete

Raw text data extracted from CAD file:

HORMIGON ESTRUCTURAL H-20 Fe d 2 cm. e=1..5mm Fe d 5 cm. e=1.5mm Fe d 5 cm. e=1.5mm Fe d 3 cm. e=1.5mm DETALLE 1 DETALLE 2 DETALLE 2 DETALLE 1
