This drawing set presents detailed bathroom elevations and sections for a residential project in Al Seyouh 16, Sharjah (UAE). The document contains 7 detailed views at 1:20 scale showing fixture placements and sanitary installations across different bathroom configurations. Specific mounting heights are indicated throughout, with vanity tops at 850mm, mirrors, and wall-mounted fixtures precisely dimensioned. The drawings feature undercounter wash basins (WB-04), wall-mounted water closets (WC-01), shower sets (SH-01), and various accessories including soap dishes (SA-03), glass shelves (SA-05), and basin mixers (SF-01). Wall finishes appear to use ceramic tiles (I-TL 201) with specific attention to waterproofing in shower areas. The uniform dimensioning system facilitates accurate contractor installation with critical heights marked from finished floor line. Construction notes reference sanitaryware specification sheets for plumbing requirements, emphasizing integration with the overall MEP systems.
Residential Bathroom Fixture Elevations and Installation Details
