Residential Building Type F Floor Plans, Elevations and Sections

Four-Story Dominican Republic Residential Building Plans

This comprehensive set of architectural drawings depicts a four-level residential apartment building (Edificio Tipo F) designed for the Residencial Bihaca project in the Dominican Republic. The drawings include detailed floor plans, elevations, sections, and evacuation routes at a scale of 1:50.

Building Specifications:
– Four levels with two apartments per floor
– Total building footprint of approximately 83 m² per floor
– First floor apartments: 74.79 m² net area per unit (81.00 m² gross)
– Second/Third floor apartments: 71.15 m² net area per unit (77.64 m² gross)
– Fourth floor apartments: 75.24 m² net area per unit (81.73 m² gross)
– Rooftop access area: 167.40 m²

Apartment Features:
– Each unit includes: master bedroom, secondary bedroom, bathroom, kitchen, dining area, living room, and balcony
– First floor includes mail boxes and communal entrance
– Central staircase provides access to all levels
– Rooftop terrace with uncovered common area

The project includes detailed emergency evacuation routes with safety elements like fire extinguishers (PQS) and emergency exit signage. The building was designed by Architect Ketty Bisono (CODIA 2647) with construction documentation dated June 2023. Notable design elements include perimeter sidewalks, defined evacuation meeting points, and clear and obvious floor-by-floor elevation transitions with NPT (Nivel Piso Terminado) heights marked throughout.
