This drawing presents comprehensive elevation details for a two-story residential villa facade system developed for the Sheikh Zayed Housing Programme. This details illustrate three facade feature elements with precise construction specifications. The facade utilizes a combination of 250mm and 300mm AAC (Autoclaved Aerated Concrete) blocks for the primary structure, supplemented with 100mm and 200mm hollow masonry blocks for non-load bearing elements. Key vertical measurements include a ground floor height of 3950mm, first floor height of 3600mm, and a total building height of 9100mm from gate level to top of parapet. The design incorporates UPVC windows with RCC lintels and sills, external plaster with paint finishes, and specific architectural elements like feature walls with 150mm projections. Section details reveal the integration of window systems with the AAC block wall assembly, providing a complete understanding of the facade construction methodology that meets the UAE residential building requirements.
Residential Facade Elevation Details with aac Block Construction System
