This drawing presents detailed sections of standard kitchen cabinetry configurations for the Sheikh Zayed Housing Programme in Al Seyouh 16, Sharjah. The detail shows four typical kitchen cabinet sections (1:10 scale) with precise vertical dimensioning. Upper cabinets are mounted at 900mm above finished floor level with a standard height of 800mm. Base cabinets stand at 900mm tall with a standard countertop height of 900mm from the finished floor. Drawer configurations include vertical spacing of 100mm between drawer units. Key features include sink base cabinet with plumbing allowance, overhead cabinet installations, and drawer runner systems. The document includes clear notation that kitchen units and equipment are for indicative purposes only and will be provided by the owner rather than included in the BOQ. All dimensions are specified in millimeters, with a 30mm kickplate height at the base of lower cabinets. The drawing represents standard configurations that combine functionality with efficient space utilization in residential kitchen applications.
Residential Kitchen Cabinet Section Details with Vertical Dimensions
