Retaining Wall Type Cartel DWG Section for AutoCAD

Retaining Wall Type Cartel DWG Section for AutoCAD

RETAINING WALL SUPPORT ONLY PUSH THE LAND US A HILLSIDE;OR SECTIONS IN TERRAIN IT IS NOT DESIGNED CONSTRUCT ON ITITS USED TO LEVEL TERRACES IN CANYONS

Drawing labels, details, and other text information extracted from the CAD file (Translated from Galician):

variable height, buttress, retaining wall, plant, section, isometric

Raw text data extracted from CAD file:

0.60 0.20 0.80 0.20 1.20 0.20 0.19 1.20 0.20 0.20 0.40 0.20 0.60 ALTURA VARIABLE CONTRAFUERTE (VER DETALLE) 4 d No. 4 + Est. d No.3 @ 0.20 PIN d No. 4 @ 0.40 0.60 5 0.80 5 1.20 5 5 1.20 5 5 5 0.20 0.60 CONTRAFUERTE SOLERA FINAL 4 d No. 4 + Est. d No.3 @ 0.20 SOLERA INTERMEDIA 4 d No. 4 + Est. d No.3 @ 0.20 4 d No. 3 + d No.3 @ 0.25 PIN d No. 4 @ 0.40 ALTURA VARIABLE MURO DE CONTENCION ESCALA 1:50 PLANTA SECCION ISOMETRICO
