Roofs DWG Block for AutoCAD

Roofs on partitions – Isolating in compression layer

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Max. Cms., Insulation in compression layer, Cover on slats, Solution placner, Protective mortar, Projected rigid insulation, Compression layer, Forged placner, Upper forged, Slats

Raw text data extracted from CAD file:

Max. 90 cms. Max. 90 cms. AISLAMIENTO EN CAPA DE COMPRESION CUBIERTA SOBRE TABIQUILLOS SOLUCION PLACNER CT-7.- MORTERO DE PROTECCION (1,5-2 cms.) AISLANTE RIGIDO O PROYECTADO CAPA DE COMPRESION ( 3 cms.) PLACNER FORJADOS FORJADO SUPERIOR TABIQUILLOS
