School Furniture Detail Drawings for Çan İstiklal Primary School

Detailed furniture specification drawings for a 12-classroom primary school in Çan, Turkey. This plans include kitchen counters with steel sinks, adjustable cabinet systems, and bathroom fixtures including accessible lavatory units. Key construction specifications include:

Materials and Construction:
– MDFLAM (laminate-covered medium-density fiberboard) for cabinet bodies with PVC edge banding
– MDKAP (white) for backing panels with insertion joints
– Steel box profile frames (50x50x2mm) with anti-corrosion treatment
– Chrome adjustable feet for leveling
– Chrome hardware and handles
– Single-bowl stainless steel sink with drainboard

Installation Requirements:

– All measurements provided in centimeters
– Adjustable chrome feet required for leveling
– Chrome handles specified throughout
– Backing panels connected via insertion joints in routed MDF panels
– Visible screw locations to be covered with adhesive caps
– Dimensions include standard units (60cm width, 80cm height) with overall assemblies measuring 177.5cm in width

The drawings include plans, elevations, sections, and construction details at 1:20 scale with specific reference to Turkish construction codes and standards.
