Site plan for the Beaufort Children’s Centre daycare facility expansion. It features a central circular track or play area bounded by a layout of deciduous trees and site landscape blocks. Full grading details are provided, showing Top of Curb (TOC) elevations and surface slope percentages for drainage management (ranging from 1.00% to 15.58%). – Layout: circular path, tree plantings, existing structures. – Civil: Manholes (MH), catch basins (CB), and various pipe fitting blocks. – Elevations: TOC points mapped between 86.50 and 87.27. Drawing is in metric (meters) and covers a substantial linear site area.
Beaufort Daycare Site Layout and Grading Plan DWG
