Partial floor plan for the second level of a P+mezanin+5 mixed-use residential building in Subotica, Serbia. The drawing shows detailed apartment layouts with specific technical information including:
Wall Construction Details:
– External facade walls (SFZ) featuring 20cm brick block, 10cm stone wool insulation, and pigmented facade plaster
– Internal walls varying between 12-25cm thick brick and reinforced concrete
– Fire protection barriers using stone wool insulation
Technical Parameters:
– Total building footprint: 1524.89 m²
– Total gross building area: 6697.99 m²
– Site occupancy: 59.38%
– Green area percentage: 20.81%
– Thermal performance values specified for wall assemblies (K-values between 0.268-0.4 W/m²K)
The plan includes architectural specifications, dimensioning, room layouts, and technical systems integration (ventilation, plumbing, electrical). Note that this sheet is labeled as the first revision to the original architectural project, with specific modifications indicated for apartments #11 and #17.
