STAIR PRESSURIZATION & SCHEMATIC DIAGRAM – PHLIPPINES PROTOTYPE
The detail of pressurization blower has a gravity relief damper. Mechanical notes. Typical control diagram of stairwell pressurization. My original work file. Thank you.
| Language | English |
| Drawing Type | Detail |
| Category | Mechanical, Electrical & Plumbing (MEP) |
| Additional Screenshots | |
| File Type | dwg |
| Materials | Other |
| Measurement Units | Metric |
| Footprint Area | |
| Building Features | |
| Tags | #stairpressurization #stairwellpressurization #pressurizestairwell #hvacplan #hvaclayout |
