Steel Framing DWG Detail for AutoCAD

Steel Framing DWG Detail for AutoCAD

Steel Framing – Monograph – Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

screws required, uprights: profile, lower base: profile, triple: profiles, quadruple: profiles, screws required, uprights: profile, lower base: profile, screws required, uprights: profile, lower base: profile, double: profiles, anchor connector, threaded rod with chemical anchor, sealant in the joint aº, valance: profile, screw between beams, stiffener: web stiffener on beam supports, foundation: zapata race of hº aº, floor girder: profile, strapping: metal strip to prevent rotating beams, substrate: multilayer phenolic mm that acts as horizontal diaphragm, lower panel base: profile, panel pillar: profile aligned with mezzanine beams, under partition, Exterior, beam under load-bearing partition, sidewalk, external partition, platea de hºaº, external termination of eifs, armor calculation, polyethylene film, poor non-structural concrete subfloor, crosslinked polyethylene pipe for heating, anchor panel foundation, panel amount: pgc, ground level, leveling folder on subfloor, thermal insulation on foundation

Raw text data extracted from CAD file:

Tornillos s/ se requiera Montantes: perfil "C" Solera inferior: perfil "U" TRIPLE: 3 perfiles "C" \A1;\fArial Narrow|b0|i0|c0|p34;Panel 1 \A1;\fArial Narrow|b0|i0|c0|p34;Panel 2 CUÁDRUPLE: 4 perfiles "C" Tornillos s/ se requiera Montantes: perfil "C" Solera inferior: perfil "U" \A1;\fArial Narrow|b0|i0|c0|p34;Panel 3 \A1;\fArial Narrow|b0|i0|c0|p34;Panel 1 \A1;\fArial Narrow|b0|i0|c0|p34;Panel 2 Tornillos s/ se requiera Montantes: perfil "C" Solera inferior: perfil "U" DOBLE: 2 perfiles "C" \A1;\fArial Narrow|b0|i0|c0|p34;Panel 1 \A1;\fArial Narrow|b0|i0|c0|p34;Panel 2 Conector de anclaje Varilla roscada con anclaje quimico Sellador en la junta Acero/Hº Aº Cenefa: perfil "U" Tornillo entre cenefa y viga (provisorio) Stiffener: rigidizador del alma en apoyos de viga Fundacion: Zapata corrida de Hº Aº Viga de piso: perfil "C" Strapping: fleje metalico c/ 1.50 m para evitar rotacion de vigas Substrato: multilaminado fenolico e=25 mm u otros, que actua como diafragma horizontal Solera inferior del panel: perfil "U" Montante de panel: perfil "C" alineado con las vigas de entrepiso \A1;viga bajo tabique portante \A1;vereda \A1;tabique exterior viga bajo tabique portante vereda tabique exterior Platea de HºAº Terminación exterior de EIFS Armadura s/ cálculo Film de polietileno Contrapiso de hormigón pobre no estructural Caño de polietileno reticulado para calefacción Anclaje del panel a la fundación Montante de panel: PGC nivel de terreno Carpeta niveladora sobre contrapiso Aislación térmica sobre fundación

Language	Spanish
Drawing Type	Detail
Category	Construction Details & Systems
Additional Screenshots
File Type	dwg
Materials	Concrete, Steel
Measurement Units
Footprint Area
Building Features
Tags	adobe, autocad, bausystem, construction system, covintec, DETAIL, details, DWG, earth lightened, erde beleuchtet, framing, losacero, plywood, sperrholz, stahlrahmen, steel, steel framing, système de construction, terre s
