Sustainable Farm House DWG Plan for AutoCAD

Sustainable Farm House DWG Plan for AutoCAD

farm house built in india ; northern karnataka. various sustainable features on site planning level ; construction techniques ; materials used for construction etc – details of plans;elevations ; setions ; images etc for detail understanding

Drawing labels, details, and other text information extracted from the CAD file:

plant, apartments, architectural design, name: amritha khuba, p . d . a. c. e, drawing n.o:, sheet n.o:, scale:, date:, course: b.arch, g . l . b, cabinet, sustainable features :, farm house, sustainable architecture, polypropylene lining, gravel, sand, soil filter, organic detritus layer, outlet ditch, liquid waste from septic tank undergoing rtzt, septic tank, reed bed, plan of fram house, pavement with grass allows water percolation, use of bouganvilla on the parapet wall helps in coolin the passing air, northern elevation, plantation with large neem tree on eastern and western side helps in cutting direct sunlight, it grows well even in poor,shallow soil and enjoys full sun, plantation of deciduous trees on southern side helps in heat penetration during winter, grouping of trees helps in wind movement yet cutting direct sun rays and is better than continuous plantation, creepers on the wall helps in prevention direct exposure of skin of the building to sunlight, orientation: the building is oriented north-south with shorter walls on eastern and western side, the given site is flat and the existing greenery is retained, windows on the northern easter and western side are provided with double glazing,reducing the heat gain, vaulted roof on the western side decreases the roof area exposed to sun making it suitable for hot dryclimate, pergola on the northern side cuts the direct sunlight, kotah stones are used for flooring which are locally available and also have good appearance, use of paints such as thermtek do not harm the environment and reduce the uv penetration through building, north eastern view, western elevation, south western view, site plan of fram house, entry, solar panels, rtzt, purified water, soil rich in humus, section at aa’, roof detail showing the use of earthern pots for roof insulation, water body, kitchen garden, double glazing on northern wall, broken white tiles, puncture for air movement, wall made of porotherm, tank for storing rain water, pipe for collecting rain water, pipe connecting to over head tank which can inturn be used to supply water to bath, gardening,washing etc, over flow pipe connected to public drain, rcc slab, inverted pots, surkhi, broken tiles, south eastern view, north western view, prevents the entry of the first rain containing impurities

Raw text data extracted from CAD file:

\A1;3.9900 \A1;0.7484 3.990000000000236 0.7483750000005784 PLANT up PLANT n APARTMENTS ARCHITECTURAL DESIGN NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: SHEET N.O: SCALE: DATE: REG NO: 3PD10AT001 CLASS: 5TH SEM COURSE: B.ARCH G . L . B CABINET \A1;0.3500 SUSTAINABLE FEATURES : SUSTAINABLE FEATURES : \W9.94118; -> NORTH SIDE IS SHADED WITH DECIDOUS/ TALLER TREES WHICH PROTECTS FROM HARSH SUN . \W2.23430; -> \W9.64969; KITCHEN GARDEN : DIRECTLY THE WATER USED FOR VEGETABLE WASHING FROM UTILITY CAN BE USED FOR GARDENING. \W9.55336; GREENERY PROVIDED ABSORB THE DIRECT SUNLIGHT & IT ALSO HELPS IN COOLING THE MAIN ACTIVITY AREA THROUGH \W9.54875; EVAPORATIVE COOLING FARM HOUSE SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B \A1;3.8800 \A1;0.1200 \A1;0.5000 \A1;0.6000 GL \W6.43357; SLUDGE \W6.40821; LIQUID \W9.19807; SCUM POLYPROPYLENE LINING GRAVEL, SAND, SOIL FILTER ORGANIC DETRITUS LAYER \W8.55495; INLET FROM HOUSE \W8.04710; OUTLET TO HOUSE \W8.97524; INSPECTION ACCESS \W8.38406; MANHOLE \W9.64553; INLET DITCH TO RTZT OUTLET DITCH \W8.87267; POROUS LID WHICH HELPS IN \W8.86335; EXHAUSTING THE STALE GASES \W8.86370; WHICH MAY CAUSE SMELLING OF \W8.86922; TREATED WATER AND THE REST \W8.86922; OF THE PORTION IS COVERED WITH \W8.85162; BAKING SODA WHICH ABSORBS THE \W8.86542; SMELLS FROM THE TANK TO THE \W8.86335; EXTERIOR REEDS (FOR OXYGEN TRANSFER AND HYDRAULIC CONDUCTIVITY) LIQUID WASTE FROM SEPTIC TANK UNDERGOING RTZT GL SEPTIC TANK REED BED \W8.85688; PURIFIED WATER WHICH CAN BE USED \W8.84209; FOR FLUSHING OF TOILETS, GARDENING, \W8.84903; WASHING VEHICLES ETC,. 3.880000000000109 0.1199999999998909 0.5 \W9.52959; 12CM THICK R.C.C SLAB \W9.43780; 50CM HT VENTILATOR \W8.37923; 23CM THICK BRICK WALL \W9.19605; 35CM THICK POROTHERM \W9.18398; BRICK WALL WITH INSULATION \W8.94686; R.C.C BEAM \W9.90278; 60CM BASEMENT WITH \W9.90217; MURRUM FILLING 0.599999999999909 B B' B \A1;4.9849 \A1;2.5993 SEPTIC TANK SEPTIC TANK \W9.98390; SEDIMENTATION \W9.99275; TANK USED \W9.96135; FOR RAIN WATER \W9.97262; HARVESTING \A1;4.2957 \A1;6.2168 \A1;2.0587 \A1;7.5143 \A1;8.4819 \A1;2.4293 \A1;0.2470 FARM HOUSE SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B FARM HOUSE SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B n dining 18sqm 2m wide porch bedroom 3.5mx4m 2m wide porch kitchen 18sqm store 4sqm kitchen garden 5.6sqm living room 18sqm sit out 5.6sqm bath 1.5mx1.8m dressing 1.6mx1.8m PLAN OF FRAM HOUSE FARM HOUSE SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B PAVEMENT WITH GRASS ALLOWS WATER PERCOLATION USE OF BOUGANVILLA ON THE PARAPET WALL HELPS IN COOLIN THE PASSING AIR FARM HOUSE SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B NORTHERN ELEVATION 5 SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B FARM HOUSE \W8.47366; \LSUSTAINABLE SITE SITE : \W9.22879; \LLANDSCAPING : PLANTATION WITH LARGE NEEM TREE ON EASTERN AND WESTERN SIDE HELPS IN CUTTING DIRECT SUNLIGHT, IT GROWS WELL EVEN IN POOR,SHALLOW SOIL AND ENJOYS FULL SUN PLANTATION OF DECIDUOUS TREES ON SOUTHERN SIDE HELPS IN HEAT PENETRATION DURING WINTER GROUPING OF TREES HELPS IN WIND MOVEMENT YET CUTTING DIRECT SUN RAYS AND IS BETTER THAN CONTINUOUS PLANTATION CREEPERS ON THE WALL HELPS IN PREVENTION DIRECT EXPOSURE OF SKIN OF THE BUILDING TO SUNLIGHT \W9.20466; \LPLANNING AND CONSTRUCTION TECHNIQUEAND CONSTRUCTION TECHNIQUE: ORIENTATION: THE BUILDING IS ORIENTED NORTH-SOUTH WITH SHORTER WALLS ON EASTERN AND WESTERN SIDE THE GIVEN SITE IS FLAT AND THE EXISTING GREENERY IS RETAINED WALLS: *THE CURVED WALLS ON EASTERN AND WESTERN SIDE HELP IN ELIMINATING EXCESS HEAT GAIN *BRICK WALLS ARE 35CM THICK, INCREASING THE TIME LAG FACTOR AND IS COMPOSED IN SUCH A WAY THAT, THE 23CM WALL IS TO THE INTERIOR PORTION AND NEXT TO IT IS CAVITY FILLED WITH INSULATING MATERIAL PERLITE AND ON THE OUTER MOST PORTION IS THE 7CM THICK BRICK WALL PLANNINGPLANNING: *COMPACT PLANNING *STEPS ON THE WESTERN SIDE WITH JALI WORK ACTS AS BUFFER FROM DIRECT HEAT GAIN *DEAD WALL ON THE NORTH WESTERN AND WESTERN SIDE HELPS IN CUTTING THE HARSH SUN AND YET ALLOWING WIND FLOW SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B FARM HOUSE \W6.78258; \LFENESTRATION : \LDEAD WALLS ARE PROVIDED WITH JALI WORKWALLS ARE PROVIDED WITH JALI WORK : 1. ALLOW CONTROLLED PASSAGE OF AIR INTO INTERIOR 2.THROW PATTERNS OF LIGHT AND SHADOW ON FLOOR ENHANCING AESTHETICS 3.DIFFUSE THE GLARE OF DIRECT SUNLIGHT WINDOWS ON THE NORTHERN EASTER AND WESTERN SIDE ARE PROVIDED WITH DOUBLE GLAZING,REDUCING THE HEAT GAIN \W7.81198; \LROOF : VAULTED ROOF ON THE WESTERN SIDE DECREASES THE ROOF AREA EXPOSED TO SUN MAKING IT SUITABLE FOR HOT DRYCLIMATE *ON THE EASTERN SIDE FLAT ROOF IS PROVIDED WHICH CAN BE USED FOR SLEEPING IN THE HOT SUMMER NIGHTS *50% OF THE HEAT ENTERS THROUGH ROOF IT IS MADE WITH MATKA SYSTEM OF ROOFING IS USED WHICH REDUCE THE HEAT PENETRATION AND IT IS LAID WITH WHITE BROKEN TILES WHICH REFLECTS LIGHT *THE SOLAR PANELS PROTECT THE ROOF FROM DIRECT SUNLIGHT AND ALSO HELP IN HARVESTING THE ABUNDANT NATURAL LIGHT AND TURNING IT INTO USABLE ELECTRICITY MAKING THE BUILDING SUSTAINABLE PERGOLA ON THE NORTHERN SIDE CUTS THE DIRECT SUNLIGHT \W8.81974; -> \LMATERIALS USED :USED : \W9.79867; \LWALLS :: \W5.40100; \LPAINTS :: \W7.00250; \LFLOORING :: KOTAH STONES ARE USED FOR FLOORING WHICH ARE LOCALLY AVAILABLE AND ALSO HAVE GOOD APPEARANCE USE OF PAINTS SUCH AS THERMTEK DO NOT HARM THE ENVIRONMENT AND REDUCE THE UV PENETRATION THROUGH BUILDING \W9.09398; THESE BLOCKS WITH INSULATINGMATERIAL. \W9.09157; ARE MANUFACTURED FROM NATURAL MATERIALSUCH \W9.09157; AS CLAY, WHICH IS MIXED WITH INGREDIENTS FROM \W9.71392; THE MINING, WASTE PAPERS THE SECRET OF ITS THERMAL \W9.72165; INSULATION IS THE AIR TRAPPED IN MANY SMALL PORES NORTH EASTERN VIEW WESTERN ELEVATION SOUTH WESTERN VIEW SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: FARM HOUSE SUSTAINABLE ARCHITECTURE REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B \W8.58935; \LWATER SUPPLY AND SANITATION SUPPLY AND SANITATION : \LWATER BODYBODY : WATER BODY ON THE SOUTHWESTER SIDE HELPS IN EVAPORATIVE COOLING OF S.W WINDS, THE POND IS PROVIDED WITH A NON-FLOATING PLANT ANACHARIS WHICH HELPS IN PURIFICATION OF WATER WHICH CAN BE USED FOR GARDENING \LKITCHEN GARDENGARDEN : THE WATER USED FOR VEGETABLE WASHING FROM UTILITY CAN BE USED FOR GARDENING. GREENERY PROVIDED ABSORB THE DIRECT SUNLIGHT *THE SHADED PORCH ON THE NORTHERN SIDE HELPS IN CUTTING DIRECT NORTHERN SUNLIGHT *THE DEAD WALL ON THE NORTH WESTERN SIDE ALSO HELPS IN CUTTING THE NORTH WESTERN SUN LIGHT B' SUSTAINABLE ARCHITECTURE NAME: AMRITHA KHUBA P . D . A. C. E DRAWING N.O: 1 SHEET N.O: 1 SCALE: DATE: REG NO: 3PD10AT001 CLASS: 6TH SEM COURSE: B.ARCH G . L . B SITE PLAN OF FRAM HOUSE ENTRY AREA=175SQM SOLAR PANELS ENTRY AREA=175SQM SOLAR PANELS n ENTRY 5 5 FARM HOUSE RTZT PURIFIED WATER \LRAIN WATER HARVESTINGWATER HARVESTING : RAIN WATER FROM THE ROOF IS COLLECTED AND PASSED THROUGH THE SEDIMENTATION TANK TO REMOVE THE IMPURITIES , THIS WATER CAN THEN BE REUSED FOR WASHING,GARDENING ETC \LGREY WATER HARVESTINGWATER HARVESTING : RAIN WATER FROM THE ROOF IS COLLECTED AND PASSED THROUGH THE RTZT TO REMOVE THE IMPURITIES , THIS WATER CAN THEN BE REUSED FOR WASHING,GARDENING ETC GL \W8.55495; INLET FROM HOUSE \W8.04710; OUTLET TO HOUSE \W9.90278; 60CM BASEMENT WITH \W9.90217; MURRUM FILLING \W6.40821; LIQUID \W7.20853; GREY WATER \W8.55495; INLET FROM HOUSE POLYPROPYLENE LINING GRAVEL, SAND, SOIL FILTER SOIL RICH IN HUMUS \W8.97524; INSPECTION ACCESS \W8.38406; MANHOLE \W9.64553; INLET DITCH TO RTZT OUTLET DITCH \W8.87267; POROUS LID WHICH HELPS IN \W8.86335; EXHAUSTING THE STALE GASES \W8.86370; WHICH MAY CAUSE SMELLING OF \W8.86922; TREATED WATER AND THE REST \W8.86922; OF THE PORTION IS COVERED WITH \W8.85162; BAKING SODA WHICH ABSORBS THE \W8.86542; SMELLS FROM THE TANK TO THE \W8.86335; EXTERIOR REEDS (FOR OXYGEN TRANSFER AND HYDRAULIC CONDUCTIVITY) LIQUID WASTE FROM SEPTIC TANK UNDERGOING RTZT SEPTIC TANK REED BED \W9.40718; PURIFIED WATER WHICH CAN BE \W9.39441; USED FOR FLUSHING OF TOILETS, \W9.41235; GARDENING,WASHING VEHICLES ETC,. 5 \W9.33655; 35CM THICK \W9.33977; EXTERNAL WALL SECTION AT AA' 1M PARAPET ROOF DETAIL SHOWING THE USE OF EARTHERN POTS FOR ROOF INSULATION 5CM CAVITY FILLED WITH PERLITE 1.2 M WINDOW 15 CM LINTLE WATER BODY KITCHEN GARDEN DOUBLE GLAZING ON NORTHERN WALL BROKEN WHITE TILES PUNCTURE FOR AIR MOVEMENT WALL MADE OF POROTHERM 5 5 5 5 5 5 50 CM SAND LAYER 50 CM AGGREGRATE LAYER 50 CM BROKEN BRICKS LAYER TANK FOR STORING RAIN WATER PIPE FOR COLLECTING RAIN WATER PIPE CONNECTING TO OVER HEAD TANK WHICH CAN INTURN BE USED TO SUPPLY WATER TO BATH, GARDENING,WASHING ETC OVER FLOW PIPE CONNECTED TO PUBLIC DRAIN RCC SLAB INVERTED POTS SURKHI BROKEN TILES SOUTH EASTERN VIEW NORTH WESTERN VIEW \LGREY WATER HARVESTINGWATER HARVESTING : RAIN WATER FROM THE ROOF IS COLLECTED AND PASSED THROUGH THE RTZT TO REMOVE THE IMPURITIES , THIS WATER CAN THEN BE REUSED FOR WASHING,GARDENING ETC PREVENTS THE ENTRY OF THE FIRST RAIN CONTAINING IMPURITIES \W9.25790; \LNATURAL AND ARTIFICIAL LIGHTINGAND ARTIFICIAL LIGHTING: \LNATURAL LIGHTINGLIGHTING : DIFFUSED LIGHTING OR INDIRECT LIGHTING IS ALWAYS PREFERRED , INDIRECT LIGHTING REDUCES HEAT GAIN AND YET ENSURES SUFFICIENT LIGHTING IN THE BUILDING IN THE DESIGN PROBLEM THIS IS ACHIEVED BY: *PORCH ON THE NORTHERN SIDE *JALI WALL ON THE WESTERN AND NORTH WESTERN SIDE \LARTIFICIAL LIGHTINGLIGHTING : LED LIGHTINGS ARE PREFERRED FOR ARTIFICIAL LIGHTING AS THEY CONSUME VERY LESS ENERGY

Language	English
Drawing Type	Plan
Category	House
Additional Screenshots
File Type	dwg
Materials	Other
Measurement Units	Metric
Footprint Area
Building Features	Garden / Park
Tags	apartamento, apartment, appartement, aufenthalt, autocad, built, casa, chalet, dwelling unit, DWG, farm, features, haus, house, india, logement, maison, northern, plan, planning, residên, residence, site, sustainable, unidade de moradia, villa, wohnung, wohnung einheit
