Tanquilla for 60x60cm sewage grate.

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Of floor, Waterproofing, Metal fence grid, of stones, Rainwater pipe, angle, Rainwater pipe

Raw text data extracted from CAD file:

\A1;0.05 \A1;0.80 \A1;0.60 \A1;0.60 \A1;0.10 \A1;0.10 \A1;0.05 \A1;NIVEL DE PISO IMPERMEABILIZACION \A1;CONCRETO REJA METALICA DE PLETINAS 1"x3/16" 5 5 5 5 5 5 \A1;LECHO DE PIEDRAS 5 TUBERIA DE AGUAS DE LLUVIAS d6" ANGULO 40x40x6mm \A1;ANCLAJES TUBERIA DE AGUAS DE LLUVIAS d6"
