Terrace Detail DWG Detail for AutoCAD

Detail railing and shelf

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Septum wall seated with mortar proportion, Flattened mortar proportion, Wire rod, Dropper, Of, Nose with radio bevel, Detail repison

Raw text data extracted from CAD file:

0.02 0.12 0.02 0.15 0.14 0.08 0.05 5 5 5 D-1.1 MURO DE TABIQUE DE 6x12x24 cm ASENTADO CON MORTERO CEMENTO-ARENA PROPORCION 1:4 5 5 5 5 APLANADO DE MORTERO CEMENTO-ARENA PROPORCION 1:4 ALAMBRON DE 1/4″ DE ø GOTERO DE 3/4″ VARILLA DE 3/8 ” DE ø NARIZ CON CHAFLAN DE 3/4″ DE RADIO DETALLE 1 REPISON
