Details tripanel – Union tripanel – boundary half-boot Section Technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

unscaled, raised, tridipane wall, in wall, finish, border shoe, vrs., its T., vrs., walking stick, vrs., of thickness, armed with, mesh, slab of, plastered with, of mortar prop.

Raw text data extracted from CAD file:

SIN ESCALA ALZADO 1.5" 1.5" MURO DE TRIDIPANEL EN MURO ACABADO 2.5" ZAPATA DE LINDERO 0.60 0.20 2 VRS. #5 2 VRS. #3 EST. #3 @25cm 2 VRS. #5 BASTON #4 0.20 0.60 0.10 @25cm 2 VRS. #3 DE ESPESOR ARMADA CON MALLA 6X6-6/6 LOSA DE 10cm 2.5" DE CAL-12.5 EMPLASTADO CON 1.5" DE MORTERO PROP. 1:4
