This technical drawing provides detailed and thorough specifications for the utility room door assembly in 4-plex townhouse end villas. The drawing presents multiple views including front elevations, side section, and plan view of the door installation. The door features a wooden frame with dimensional specifications showing a clear opening width of approximately 800mm and height of 2100mm. The door assembly includes architraves, ironmongery, seals, and proper wall integration details. The drawing indicates floor levels (0.00+) and incorporates proper threshold detailing. The design addresses both left and right end villa configurations with identical door requirements (01 No. per unit). Construction details show proper integration with flooring materials and wall finishes, including packers and stone elements. The installation follows UAE construction practices with specific attention to door frame anchoring and sealing techniques to ensure durability in the utility room environment.
Utility Room Door Detail Plan & Elevations for End Villa Units
