Washer Basin Of Column DWG Detail for AutoCAD

Washer Basin Of Column DWG Detail for AutoCAD

Wash basin installation with column – Detail with technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Portuguese):

front view, finished floor, scale:, subtitle, side view, finished floor, front view, cold sewage pvc weldable with flexible metal thread for drain with sink thief pvc weldable with pvc thread for secondary sewage pvc short warm water bronze bolsaxbola nipple bronze

Raw text data extracted from CAD file:

\A1;0.80 \A1;0.50 \A1;0.60 \A1;0.20 \A1;0.60 \A1;0.50 \A1;0.80 VISTA DE FRENTE PISO ACABADO ESCALA: 1:1 LEGENDA AQ AF VISTA LATERAL 6 PISO ACABADO 1 5 2 3 4 7 7 6 VISTA DE FRENTE 0.80 0.50 0.60 0.20 0.60 0.50 0.80 \C3;ÁGUA FRIA E ESGOTO 1-JOELHO 90° PVC SOLDÁVEL E COM ROSCA METÁLICA d 20mmx1/2" 2-LIGAÇÃO FLEXÍVEL 3-VÁLVULA DE ESCOAMENTO PARA LAVATÓRIO COM LADRÃO 4-SIFÃO PARA LAVATÓRIO d 1x1.1/2" 5-JOELHO 90° PVC SOLDÁVEL E COM ROSCA d 40mmx1.1/2" 6-TUBO PVC PARA ESGOTO SECUNDÁRIO d 40mm 7-CURVA 90d PVC CURTA d 40mm ÁGUA QUENTE 1-COTOVELO DE BRONZE BOLSAxBOLA d 20mmx1/2" E NIPLE DE BRONZE d 1/2"

Language	Portuguese
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, basin, column, DETAIL, DWG, einrichtungen, facilities, gas, gesundheit, installation, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, specifications, technical, wash, washer, wasser bestimmung, water
