Well A And B DWG Detail for AutoCAD

Well A And B DWG Detail for AutoCAD

Detail well of inspection

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Min. Greater equal mts., The type well will be used for depths, plant, The type well will be used for depths, note:, Greater than mts., plant, water well, Flattened, cut, mortar, Flattened with, cut, Stone masonry, With mortar proportion, Stairs with, Rod of, Septum, With mortar, water well, Concrete crusher, Of cast iron, variable

Raw text data extracted from CAD file:

* * MENORES DE 2.50 Mts. Y MAYORES o IGUALES A 1.10 Mts. EL POZO DE TIPO "B" SE USARA PARA PROFUNDIDADES PLANTA EL POZO TIPO "A" SE USARA PARA PROFUNDIDADES NOTA: MAYORES DE 2.50 Mts. PLANTA 1.75 A 0.28 B POZO "B" APLANADO 1:2 CORTE A-A 1.20 B 0.20 MORTERO 1:2 APLANADO CON CORTE B-B 1.75 1.20 0.90 MAMPOSTERIA DE PIEDRA CON MORTERO PROPORCION 1:5 A ESCALERAS CON VARILLA DE 1"d. TABIQUE JUNTEADO CON MORTERO 1:4 1.20 POZO "A" BROCAL DE CONCRETO o DE FIERRO FUNDIDO 0.60 0.90 VARIABLE

Language	Spanish
Drawing Type	Detail
Category	Water Sewage & Electricity Infrastructure
Additional Screenshots
File Type	dwg
Materials	Concrete, Masonry
Measurement Units
Footprint Area
Building Features
Tags	autocad, DETAIL, DWG, inspection, kläranlage, treatment plant
