Windows At Inclined Roofs DWG Block for AutoCAD

Two groups window GGL Vertical window

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

dismount the adjustable profile and seal, clearance., efw flashing, lower gutter, finishing, mortar regularization, union ggl and vfe sealed, asphalt cloth, flashing efw, upper gutter, separator, drainage channel, note:, rastrel, velux is a registered trademark, ggl window and window set, vertical vfe with flashing efw., anchor pre-frame, anchor brackets, red line, flashing efw channel side, tiles, cement, facade, efw, vfe

Raw text data extracted from CAD file:

100 mm 30-60mm 30-60mm 60-150mm 10-15mm min. 130mm Junta>15mm min. 30 mm min. 15 mm Seccion B-B 1:5 Si la junta tiene mas de 15 mm, desmonte el perfil ajustable y selle la holgura. min. 130mm min. 30 mm Tapajuntas EFW, canalon inferior / 1996 VELUX GROUP C Remate Mortero de regularizacion Union GGL y VFE sellada / / Tela asfaltica / 30-60mm Tapajuntas EFW, canalon superior 1:40 Seccion A-A 1:5 / C C C A C A B B A B A B V-E 3VO.217.5.52/14.11.96 Separador 60-150mm / Canal de drenaje NOTA: Rastrel VELUX es una marca registrada 11.96 10.13 Conjunto de ventana GGL y ventana vertical VFE con tapajuntas EFW. R Premarco de anclaje Escuadras de anclaje Linea roja / 100 mm min. 15 mm max 2692 mm Tapajuntas EFW canal lateral 30-60mm -83.59272828464873 Tejas de cemento Fachada Seccion C-C 1:10 Junta>15mm 10-15mm 100 mm / min. 130mm min. 30mm VFE+40mm Linea roja Rastrel EFW GGL/ VFE \A1;min. 130mm \A1;min. 30 mm \A1;30-60mm \A1;60-150mm \A1;100 mm \A1;30-60mm \A1;Junta>15mm \A1;10-15mm
