This detailed shop drawing presents a D6 90-minute fire-rated wood door assembly with comprehensive sectional views. The drawing showcases the door’s veneer finish with distinctive grain pattern, frame construction, and hardware positioning. Key technical specifications include a fire rating of 90 minutes (D6 classification) with proper intumescent seals around the perimeter. The assembly features multiple components including the architrave, carcass, subframe, and essential ironmongery. Sectional details illustrate the door swing operation with approximately 3-inch frame depth and standard 1.2-inch door thickness. The drawing includes precise connection details between the door and surrounding wall structure, with proper sealing methods at thresholds. Hardware locations are dimensioned according to fire code requirements, ensuring compliant installation in commercial or institutional applications where extended fire resistance is mandatory.
90-Minute Fire-Rated Wood Door Detail Drawing with Frame assembly
