Absorbing Well – Details

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

pvc tube, to filter, decline ml, section, continuous in, every corner from, motherboard, DC., liquid depth, det. of septic filter, scale., cont., with steel handle, concrete cover, both senses, recebo, plant, Drainage length, mts

Raw text data extracted from CAD file:

\A1;.15 \A1;.15 \A1;1.70 \A1;.15 \A1;2.00 \A1;.15 \A1;1.70 \A1;.15 \A1;2.00 \A1;.60 \A1;.60 \A1;.30 \A1;1.70 \A1;.30 \A1;.15 \A1;.20 #4@30cms TUBO 4″ PVC. TUBO 4″ PVC. HACIA FILTRANTE DECLIVE 1cm x ML (MINIMO) SECCION 2#5 CONTINUAS EN CADA ESQUINA DESDE PLACA BASE #3@30 C.C. PROFUNDIDAD LIQUIDA DET. DE POZO SEPTICO Y FILTRANTE (TIPICO) ESCALA. 1:25 2 # 5 CONT. CON TIRADOR DE ACERO TAPA EN HORMIGON 60 x 60cms 5 5 5 5 5 5 5 5 5 5 5 5 1.70 .30 ambos sentidos RECEBO 5 5 PLANTA LONGITUD DRENAJE 10 Mts
