Comprehensive architectural implementation drawings for a two-story academic facility featuring ground and first floor plans with three detailed building sections (A-A, B-B, C-C). This building includes conference rooms, offices, exhibition halls, classrooms, and service areas with clearly defined circulation paths. Floor heights range from +4.60m (first floor) to +9.03m (roof level). Wall systems include concrete, gypsum panel, and wood partition walls with detailed material specifications. Interior finishes predominantly feature marble flooring, decorative plaster, and mesh suspended ceilings, with specialized acoustic treatments in exhibition and conference spaces. Steel stair constructions with wooden treads connect the floors. Accessibility features include a 6% incline ramp and handicap-accessible restrooms. Room schedules provide detailed material specifications for floors, walls, ceilings, and baseboards for all 40+ uniquely numbered spaces.
Academic Building Implementation Floor Plans and Sections 1:50
