Armed concrete orchestra – Beam under blocks amble – Technical specifications

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Exterior, under load bearing partition, platea de hºaº, common brick, external partition, beam under load bearing partition, sidewalk, polyethylene film, plaster rock plate, Panel stile: pgc, vapor barrier, air chamber, stiffening diaphragm, wind water barrier: overlapping with wall passing under the masonry, sewer system

Raw text data extracted from CAD file:

\A1;tabique exterior \A1;viga bajo tabique portante \A1;vereda Platea de HºAº Ladrillo común tabique exterior viga bajo tabique portante vereda Film de polietileno Placa de roca de yeso Montante de panel: PGC Barrera de vapor Cámara de aire Diafragma de rigidización Barrera de agua y viento: solapada con pared pasando debajo de la mampostería Drenaje
