2D architectural plan blocks of single and double swing doors organized by opening width and wall thickness. This DWG file includes precise symbols for doors ranging from approx. 0.55m to 1.20m, with a standard height of 213cm. Each block accounts for specific rough opening dimensions (buque) and frame details, including counter-frames.
The collection provides tailored geometry for 12cm, 15cm, and 18cm wall types, including masonry block and gypsum partitions. These blocks include data for plaster finishes (repello) and specific wooden frame configurations. Pared de bloques y gypsum.
