Commercial kitchen MEP project for a restaurant renovation. Incl. full HVAC ducting plans, exhaust hood schedules (3 hoods @ 1,814 CMH each), and diffuser layouts. We’ve included both “before” and “after” plans for the plumbing, covering grease trap (GT) links, drainage, and water supply (sizes 15A up to 50A). Gas piping is there too with carbon steel specs & leak alarm notes.. Sprinkler layouts show 79°C and 105°C heads plus the K-class kitchen fire suppression. You get the general mechanical detail sheets as well, pipe hangers, wall sleeves, insulation types, etc. 기계설비 및 기계소방 도면 포함. 냉난방배관, 급수급탕, 오배수, 환기덕트 및 스프링클러 평면도 수록.
Commercial Kitchen MEP Set HVAC Plumbing and Fire Protection
