Cp Irrigation System Of San Cristobal De Corma DWG Full Project for AutoCAD
irrigation project for the town of the district Corma MIRG Antonio Raimondi Province Ancash Department consisting of 01 geo-membrane reservoir of 750m3, well of energy dissipation sand trap, and valve outlet box, switch box, laterals, retaining wall and perimeter fence of the plant.
| Language | Other |
| Drawing Type | Full Project |
| Category | Water Sewage & Electricity Infrastructure |
| Additional Screenshots | |
| File Type | dwg |
| Materials | |
| Measurement Units | Metric |
| Footprint Area | |
| Building Features | |
| Tags | ancash, antonio, autocad, cristobal, de, distribution, district, DWG, fornecimento de água, full, irrigation, kläranlage, l'approvisionnement en eau, Project, province, san, sand trap, supply, system, town, treatment plant, wasserversorgung, water |
