Damper gas – Detail

Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):

Regulatory detail, front view, Msb mod controller, Ball Valve, Insulation cupl, Flat double joint, Tee reduction, Elbow reduction, Elbow reduction, Tee reduction, Meters with low pressure, Service from external network, Ball Valve, Ball valves, Coating level

Raw text data extracted from CAD file:

\A1;0.80 \A1;1.10 \A1;0.20 \A1;0.13 \A1;0.11 \A1;0.22 \A1;0.22 \A1;0.35 \A1;0.05 \A1;0.83 5 5 5 5 5 DETALLE REGULADOR VISTA FRONTAL 5 5 5 5 5 Regulador MSB Mod B100 Válvula esférica Ø 2'' Cupla aislante Ø 2'' Unión doble plana Ø 2'' Tee de reducción Ø 2''x1¼'' Codo reducción Ø 2''x1¼'' \A1;co Codo reducción Ø 2½''x1½'' Tee de reducción Ø 2½''x1½'' a medidores con baja presión Servicio desde Red externa Válvula esférica Ø 1¼'' Válvulas esféricas Ø 1½'' Ø 1¼'' S2000 Ø 2½'' Ø 1¼'' S2000 Ø 1¼'' S2000 Ø 2'' S2000 Ø 1½'' IRAM2548 Ø 1½'' IRAM2548 Ø 1½'' IRAM2548 Nivel de revestimiento

Language	Spanish
Drawing Type	Detail
Category	Mechanical, Electrical & Plumbing (MEP)
Additional Screenshots
File Type	dwg
Materials
Measurement Units
Footprint Area
Building Features
Tags	autocad, damper, DETAIL, DWG, einrichtungen, facilities, gas, gesundheit, l'approvisionnement en eau, la sant, le gaz, machine room, maquinas, maschinenrauminstallations, provision, wasser bestimmung, water
