Male locator part drawing from Eaton (model -4, drawing CPS-1335-T-1-19). I’ve got a couple details here—Detail A shows the side profile with the .800 head and .249 diameter shank, while Detail B covers the 8-32 thru-tap. It’s a precise mechanical piece meant to be made from A2 steel and hardened to Rc 46-50. All the dimensions are in inches, with tight tolerances like .005 on the three-place decimals. There’s also some specific finish notes per ISO 1302 and concentricity specs.The dwg file is from an older version of AutoCAD so it should open in pretty much anything.
Eaton -4 Male Locator Mechanical CAD Detail DWG
