First basement level electrical outlet distribution plan for Edificio Hernando de Aguirre, a two-building residential complex. Scale 1:125. The plan details power outlet installations throughout the basement, including:
Key Features:
– Standard 10A lighting outlets and 16A power outlets
– Specialized connections for building services (extraction systems, water pumps, pressurization)
– Emergency lighting fixtures and escape signage
– CCTV camera connection points
– Distribution panels for common areas and individual apartments
The basement includes parking areas, mechanical rooms, waste collection facilities, and utility spaces serving both buildings. Service rooms include equipment for water pumps, pressurization systems, and extraction systems. The parking ramp has a 9.6-15% gradient. Installation details show electrical conduit specifications, mounting requirements for emergency signage, and IP67 protection-grade outlets with 250°C silicone cabling for emergency services.
