This technical drawing depicts a precision cover plate (labeled ‘COVER’ in the title block) for an electronic component with model number ESM0404A01441. This drawing shows a rectangular cover with specific dimensional requirements measured in millimeters.
Key Dimensions:
– Length: 150 mm total length
– Width: 45 mm total width
– Interior dimensions include measurements at 0, 3, 15, 42, 45, and 135 mm points
– Tolerance specifications appear to range from 0.05 to 0.3
The drawing is structured in a standard A4 format with a title block containing manufacturing information in Chinese characters. The drawing includes reference points and dimensional annotations that indicate precise manufacturing requirements for the component. This appears to be a manufacturing reference document (indicated by the filename prefix “FOR廠商僅供參考”) intended for production specifications of an electronic enclosure part, likely used in industrial applications or consumer electronics assembly.
