Facade Section DWG Section for AutoCAD
From fundations to roof
Drawing labels, details, and other text information extracted from the CAD file (Translated from Spanish):
crushed gravel layer, gripping mortar, rustic stoneware socket, waterproofing membrane, rustic stoneware pavement cm, Reinforced concrete wall according to plan, concrete slab: electrowelded mesh, compacted bowling, natural terrain, cleaning concrete, zapata run according to plan, gripping mortar, rustic stoneware pavement cm, rustic stoneware socket, natural stone cladding, waterproofing membrane, reinforced concrete beam according to plan, gripping mortar, terrazzo socket, medium grain terrazzo pavement, gripping mortar, terrazzo socket, medium grain terrazzo pavement, curved ceramic tile, gripping mortar, waterproofing sheet, projected polyurethane insulation, ceramic bard, monolayer mortar, thermo clay block cm, thermal isolation, iron handrail, blind box, wood carpentry lacquered wood color, colorless glass climalit, blind, gypsum plaster, iron handrail, blind box, wood carpentry lacquered wood color, colorless glass climalit, blind, gypsum plaster, natural stone flashing, reinforced concrete beam according to plan, natural stone flashing, prestressed concrete lintel, reinforced concrete beam according to plan, prestressed concrete lintel, monolayer mortar
Raw text data extracted from CAD file:
| Language | Spanish |
| Drawing Type | Section |
| Category | Construction Details & Systems |
| Additional Screenshots |
 |
| File Type | dwg |
| Materials | Concrete, Glass, Wood |
| Measurement Units | |
| Footprint Area | |
| Building Features | |
| Tags | autocad, construction details section, cut construction details, DWG, facade, fundations, roof, section |
