Technical drawing of a belt conveyor system featuring a 650mm width belt with a total length of approximately 9750mm. The system includes a 500mm diameter drive pulley, a 9° incline angle, and a tensioning mechanism with 200mm adjustment capacity. Key dimensions include five 300mm sections (totaling 1500mm) for modular construction and a 3000mm primary conveyor section. The drawing details both plan and elevation views, illustrating the drive assembly, idler rollers, and support structure. Notable technical elements include the marked height elevations (+7.700 and +8.700), suggesting a vertical rise of 1000mm, and specialized roller configurations at transfer points. The tension adjustment mechanism allows for proper belt tracking and operational tension maintenance – a critical feature for preventing premature wear and ensuring consistent material flow.
Industrial Belt conveyor System – Tensioning & Drive Assembly Detail
