Luxury Villa Ground Floor Plan with Swimming Pool and LPG System

This comprehensive ground floor plan for a luxury villa showcases a sophisticated architectural layout with multiple connected spaces. The drawing indicates a sizeable swimming pool integrated into the design, alongside technical infrastructure including a 500-gallon LPG tank installation and a 60 cubic meter (13,200 imperial gallon) GRP domestic water storage system. The water system includes booster pumps (duty/standby configuration) with VFD control panels and a 150-liter pressure vessel, delivering 8L/s at 20m head. The floor layout features numerous designated spaces (labeled GF-01a through GF-44) with careful attention to circulation paths. The drawing indicates multiple elevation points ranging from 0.00+ to 10.50+, establishing the vertical relationship between spaces. Track rails are incorporated into several areas, suggesting automated systems or movable partitions. The detailed technical specifications and infrastructure integration demonstrate a high-end residential development with sophisticated MEP requirements.
