This comprehensive set of architectural drawings depicts a one-story bungalow residential house in Bataan, Philippines. The floor plan features a living area, dining area, kitchen, master bedroom with en-suite bathroom, and two additional bedrooms with a shared bathroom. Key measurements include a finished floor level (FFL) of +350mm above natural ground level (NGL), with the terrace at +200mm. The construction employs concrete foundations with wall footings, concrete columns, and a truss roof system. Interior finishes include 300×300×6mm ceramic tile flooring, gypsum board ceilings with trim, and various door types ranging from 1.0-1.2m in width. The drawings include detailed baluster elements, eave sections, and roof details with appropriate ventilation. The site development plan indicates property boundaries adjacent to a road, with proper setbacks and landscaping elements. The plumbing system includes septic tank connections, and the electrical plan shows both lighting and power layouts with appropriate fixture placement throughout.
One-Story Bungalow Residential Floor Plan with Truss Roof System
