3D AutoCAD model of a single pallet racking storage module based on the SLP system. The assembly includes four perforated upright columns with bolt-down base plates, horizontal load-bearing beams, and diagonal structural bracing. Metric dimensions indicate a standard footprint of 1200mm x 1000mm with vertical section markers at 800mm and 1100mm.
The drawing provides a rendered 3D perspective and a dimensioned wireframe layout. Material specifications within the file include steel and aluminum with galvanized (zinc) finishes. This model is used for warehouse interiors, logistics facility planning, and industrial storage configurations. SLP csomópont.
